BZT PFLCompact, precise, versatile
The PFL series is a versatile CNC gantry mill for beginners and trades — ideal for wood, plastic and soft metals.
Technical data sheet — PFL
Click page to enlarge · pinch to zoom on smartphone
Design & Details
What defines the PFL
Work area
- Clamping area X × Y
- 250 – 500 × 530 – 775 mm
- Travel X | Y | Z
- 260 – 520 | 380 – 620 | 100 mm
- X/Z axis
- Aluminium
Drive & mechanics
- Traverse speed
- approx. 5000 mm/min
- Drive
- Stepper motors 4 A / 3 Nm
- Ball screws
- X | Y = 16 x 10 mm | Z = 16 x 5 mm
- Linear guides
- X | Y = 25 mm | Z = 15 mm
- Milling spindle usable up to
- 1 kW
General
- T-slot plate (aluminium)
- 15 mm thickness
- Front/end plate
- Steel
- Outer dimensions (W × D × H)
- 620 – 1240 × 640 – 1280 × 520 mm
- Control system
- USB control U-ST 43.3, 3 axes, 4 amperes
- Category
- Entry-level & trade
- Special feature
- Compact entry-level milling machine, steel frame
Design
Ball screws in all axes for precise movements.
Linear guides 15 and 25 mm, ground and surface-hardened – unique in this price class.
Closed linear guide system with concealed, protected guides and guide carriages.
KTR couplings between stepper motor and drive screw.
Travels up to 600 × 400 mm.
Sturdy steel frame, front and end plate made of steel, X/Z axis made of aluminium.
T-slot plate 15 mm included (optional 20 mm thickness).
Control & drive
USB control U-ST 43.3, 3 axes, 4 amperes – compact and inexpensive, controls up to 3 axes simultaneously.
Stepper motors 4 A / 3 Nm.
BZT CNC control software included with the purchase of a control unit.
Control options: U-ST 33.1 (3.0 A) or E-ST 43.3 (4.0 A).
Applications & Materials
Applications and Materials:
During milling, some materials require cooling.
Good to know about the PFL series
Which materials can the BZT PFL machine?
How fast does the PFL series work?
Where is the PFL series manufactured?
How can I request a quote for the PFL?
Consultation on the PFL series
We help you choose the right size and configuration — spindle, control, table type and options. You will receive an individual quote.
What is the BZT PFL series?
The PFL series is a compact CNC gantry milling machine for entry-level users and trade – ideal for milling, engraving and model making on a limited footprint. The sturdy construction with linear guides and ball screws in all axes ensures smooth, precise movements and a switching accuracy of up to 0.02 mm. Travels of 300 to 900 mm in the X axis and 200 to 400 mm in the Y axis cover typical workshop applications. Suitable for wood, plastic, foams and soft aluminium alloys. Optionally expandable with spindles up to 1 kW.
