BZT PFH 1515-G
For diverse industrial CNC milling operations
Specifications of the BZT PFH 1515-G
Working area
- Travel X
- 1520 mm
- Travel Y
- 1510 mm
- Travel Z
- 170 mm
- Clamping surface X
- 1500 mm
- Clamping surface Y
- 1500 mm
- Clearance height Z
- 250 mm
Drive & mechanics
- Drive
- Servomotor 750 W / 7.16 Nm (optional)
- Rapid traverse
- X+Y 12000 mm/min, Z 10000 mm/min
- Repeatability
- 0.02–0.03 mm (gemessen auf der Festlagerseite)
- Ball screw X
- 16 x 16 mm
- Ball screw Y
- 25 x 10 mm
- Ball screw Z
- 16 x 5 mm
- Linear guide
- Bosch Rexroth 25 mm in X | Y | Z
General
- Power supply
- 330 V / 50 Hz
- Outer dimensions
- 2000 x 2200 x 2300 mm
Data sheet — BZT PFH 1515-G
Click page to enlarge · pinch to zoom on smartphone
The data sheet shows all model variants of the PFH series. The exact values for this machine can be found in the table above.
Why the PFH series stands out
Design & mechanics
Ball screws, linear guides and guide carriages from Bosch Rexroth.
Steel side panels in C design; concealed guides protect sensitive components from contamination.
Driven nut in the X and Y axis ensures high precision and smooth running when machining panel material.
2 ball screws Ø 25 mm in the Y axis (gantry design) with ball screw support.
Stable X axis made of steel beam 200 x 100 mm with double side panels allows the use of HF spindles up to 15 kW.
Large, stable Z axis, suitable for HF spindles up to 15 kW.
Ergonomic design: the feet are positioned on the inside; particularly suitable for panel machining.
Control & drive
CNC controller optionally from OSAI, Heidenhain or Siemens.
Servo drive 750 W / 7.16 Nm optionally available.
Optional automatic tool changer, up to 2x 8-position or 2x 16-position disc changer on the gantry.
Options: vacuum table, T-slot plate (15 or 20 mm), rotary axis/swivel head for 5-axis machining.
Applications & Materials
Maximum Precision for Your Projects with the BZT PFH 1515-G
The BZT PFH 1515-G offers you the perfect combination of stability and precision. Ideal for machining sheet material, it delivers excellent results thanks to its robust gantry design and high-quality components. Rely on the performance of this CNC gantry milling machine and optimise your manufacturing processes.
Highlights & Benefits
- Stable steel X axis for maximum load capacity
- Precise machining thanks to driven nut in the X and Y axes
- Covered side guides protect against contamination
- Smooth running thanks to ball screws and linear guides from Bosch
- Use of powerful HF spindles up to 15 kW
Technical Specifications
| Property | Details |
|---|---|
| Machine model | BZT PFH 1515-G |
| X axis | Steel, stable |
| Y axis | Gantry design |
| HF spindle | Up to 15 kW |
| Guides | Ball screws, linear guides from Bosch |
| Protection | Covered side guides |
The BZT PFH 1515-G offers “Made in Germany” quality and helps you increase your efficiency.
